Dimensions |
9.91”H x 3.21”W x 1.20”D
|
|
Material |
ABS plastic rated UL-94V-0 |
|
Power |
(No AC Power) 15-35 VDC@50mA Max |
|
Sensing Elements |
VOCs- Micro-machined Metal Oxide
|
|
VOC Detection Range |
0-5,000 PPM equivalent |
|
Response Time |
Less than 60 Sec. (after Start-up Time) |
| Start-up Time |
15 Minutes |
| Operating Environment |
32-122°F (0-50°C); 0-95% RH non-condensing;
±100 ppp CO2 Equivalent Contaminants in
2 ppm increments
|
| Analog Outputs (1-0-10VDC) |
VOC Contaminants: 0-100% |
| LED Level Indicator |
Good, Green <2,500 PPM
Fair, Yellow = 2,500 to 3,500 PPM
Poor, Red > 3,500 PPM
|
| Certifications |
RoHS |
| Warranty Period |
Two years from manufacture date |
